Admiralty Brass Tube Symbol:
| Grade | USA | UK | Germany | Japan | ||
| China GB | UNS | EN | DIN | No | JIS | |
| HSn70-1 | C44300 | CuZn28Sn1 | CW708R | CuZn28Sn1 | 2.0490 | C4430 |
Chemical Composition:
| Standard | Chemical Composition | ||||||||||||||
| Cn | Sn | Al | As | Ni | Fe | Mn | Pb | B | P | Si | S | C | Zn | Other | |
| C44300 | 70.0-73.0 | 0.9-1.2 | 0.02-0.06 | 0.06 Max | 0.07Max | Rem | |||||||||
Dimensions:
Outer diameter: 5-350mm;
Wall thickness: 0.5-50mm according to the buyers' requirements.
Standard: GB/T8890 / ASTM B111 / JIS H3300 / BS EN12451 standards
Application: Admiralty Brass Tube C44300 used for condenser and heat ex-changers, Water Evaporators, Boiler Blow down Heat Ex-changers, air coolers, Gland Steam Condensers, Steam Ejector, Turbine Oil Coolers, Fuel Oil Heaters, Compressed Air Inter and After Coolers, Ferrules, Oil Well Pump Liner, and Distiller etc.
