Hastelloy C22 UNS N06022

Share

Chemical Composition:

%NiCrMoFeWCoCMnSiPSV
minbalance20.012.52.02.5






max22.514.56.03.52.50.0150.50.080.020.020.35

Product Types and Standard:

FormASTM
RodB 574
Plate, sheet and stripB 575
Seamless pipe and tubeB 622
Welded pipeB 619, B 775
Welded tubeB 626, B 751
Welding fittingB 366
Forged or rolled pipe flange and forged fittingB 462
Billet and bar for reforgingB 472
ForgingB 564

Physical Properties:

Density8.69 g/cm3
Melting range1325-1370℃

Features: Hastelloy C-22 is a versatile Ni-Cr-Mo-W alloy with better comprehensive corrosion resistance performance than other Ni-Cr-Mo alloys, including Hastelloy C-276, Hastelloy C-4 and Inconel 625. Hastelloy C-22 has outstanding resistance to pitting, crevice corrosion and stress corrosion cracking. It has excellent resistance to oxidizing aqueous media including wet chlorine and mixtures containing nitric acid or oxidizing acids with chloride ions. It also offers optimum resistance to environments where reducing and oxidizing conditions are encountered in process streams. So it can be used where "upset" conditions are likely to occur or in multipurpose plants. Hastelloy C-22 has exceptional resistance to a wide variety of chemical process environments, including strong oxidizers such as ferric and cupric chlorides, chlorine, hot contaminated solutions (organic and inorganic), formic and acetic acids, acetic anhydride, and seawater and brine solutions. It resists the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition.

Applications: Chemical processing involving acetic acid, acetic anhydride and complex acid mixture; pickling operations; cellophane manufacture; chlorination systems; electri - galvanizing rolls, expansion bellows; flue gas scrubber systems; geothermal wells; HF furnace scrubbers; incineration scrubbers; nuclear fuel reprocessing; pesticide production; phosphoric acid production; heat exchangers; selective leaching systems; sulfur dioxide cooling towers; sul phonation systems; and weld overlay.
